Understanding Electric Wye Connections
The image shows two electrical diagrams from a textbook page illustrating Wye-connected alternator voltage systems. The top diagram shows phase-to-neutral voltages labeled as 120V, with text 'E LINE = E PHASE'. The bottom diagram shows phase-to-phase voltages labeled as 208V, with green boxes highlighting 'I LINE = I PHASE' and 'E LINE = 1.73 x E PHASE'. The joke is that the text overlays are mislabeling the current and voltage relationships in a Wye system, implying the 'E LINE = 1.73 x E PHASE' is a common mistake or oversimplification.
